LiftMaster Elite CSW200501UL-MC 1/2 HP Swing Gate Operator
• 8' x 1,600 Lbs / 18' x 600 Lbs
• 110VAC Power Source / 110VAC Operating Voltage
• Opens 90° ~ 13 - 15 Seconds
• Continuous Duty
• Includes Receiver & Photo Eye
• 7 / 5-Year Limited Manufacturer Warranty
MPN:
CSW200501UL-MC
From $2,610.00
To $3,196.00
SKU
LFM-csw200501ul-mc-bundle
Product Details
Built for high-traffic applications and engineered for safety, the CSW200 models of swing gate operators are the first choice for heavy-traffic applications such as large gated communities, residential developments, commercial complexes and private estates. Liftmaster Elite Series gate operators feature the highest quality components and are backed by years of proven reliability.
Access your property like never before. With MyQ Technology you can monitor and control your gate from anywhere and get in quickly and securely with the built-in interference eliminating Security+ 2.0 radio. Industry-leading power management technology delivers power when you need it most to operate your gate and minimizes power draw at all other times.
Suitable Gate Dimensions:
12' x 2000 Lbs16' x 1600 Lbs
18' x 1400 Lbs
22' x 1000 Lbs
CONNECTIVITY
- MyQ Technology enables you to securely control and monitor your gate operator from anywhere and get activity notifications through the MyQ App
- Wireless Dual-Gate Communication eliminates expensive conduit costs and avoids unsightly driveway scars
PERFORMANCE
- P3 Motors purpose-built high-cycle high temperature continuous duty motor with class H (high-temperature) insulation
- Legacy Elite heavy-duty commercial gear-driven transmission provides unsurpassed reliability
- Soft mid-travel reversal extends hardware life in high-cycle and heavy-gate applications
- Weatherproof high-density polyethylene UV-resistant cover
- 1/4 in. gold zinc plated chassis eliminates corrosion
- 2-digit LED diagnostic display
- Integrated Plug-In Loop Detector inputs
- Bi-part delay
- 2 auxiliary power outlets
- Timer-to-Close adjustable from 0 – 180 seconds
- Power ON/OFF switch
- High-speed precision limit switches
SAFETY
- Includes Monitored Retro-Reflective Photo Eye (LMRRU)
- Monitored safety inputs with colored terminal blocks (3 on main board, 3 on expansion board)
- UL /cUL Listed, tested to the most stringent industry guidelines
- Security+ 2.0 Technology access your property quickly with Security+ 2.0 Technology that utilizes a tri-band signal that virtually eliminates interference and offers extended range each time the remote is used
- 3-channel receiver – OPEN/CLOSE/STOP
- Compatible with HOMELINK version 4 and higher
- Receiver stores up to 50 remote controls
- Inherent reversing sensor detects obstructions or increased loads. Reverses gate when closing or stops/reverses the gate when opening
- Pre-motion warning alarm
- External alarm reset button
- Surge suppression/lightning protection up to 50 ft. away
- Non-scissoring gate arm with emergency release handle that maintains limits once re-engaged
| Manufacturer Part Number | CSW200501UL-MC |
|---|---|
| Former Part Number | csw200501, csw200501u, csw200501ul |
| Brand | Liftmaster |
Showcased Accessories
- Gate Locks
- Gate Operator Accessories
- Stand-Alone Access Control
- Multiple Unit / Access Point Control Systems
- Radio Remotes
- Emergency Access
- Access Control Accessories
- Loop Detectors
- Loops
- Photo Eyes
- Safety Edges
- All Products
- Google Feed
Product Manuals
Product Brochures
Additional Resources
-
31====
-
Liftmaster K1D8387-1CC Expansion BoardLFM-k1d8387-1cc K1D8387-1CC• Expansion Board, UL325See More Details
• For Post-2016 DC operators
• Circuit Boards are Non Returnable$210.50
31==== -
LiftMaster Elite K07-50227 Shaft - OutputLFM-k07-50227 K07-50227• Output ShaftSee More Details
• 1-3 Week Lead Time$73.75
31==== -
LiftMaster Elite K09-50119 Output ArmLFM-k09-50119 K09-50119• Output ArmSee More Details
• 1-3 Week Lead Time$69.25
31==== -
LiftMaster K13-34729 CoverLFM-K13-34729 K13-34729• E-Box CoverSee More Details
• 1-3 Week Lead Time$30.50
31==== -
Liftmaster K13-36117-1 CoverLFM-k13-36117-1 K13-36117-1• Cludge CoverSee More Details
• 1-3 Week Lead Time$34.00
31==== -
LiftMaster Elite K13-50260 CoverLFM-k13-50260 K13-50260• Cludge CoverSee More Details
• CSW and ROBO Series
• 1-3 Week Lead Time$27.50
31==== -
LiftMaster Elite K19-50048 Chain - #50LFM-k19-50048 K19-50048• #50 ChainSee More Details
• CSW200UL
• 1-3 Week Lead Time$24.25
31==== -
Liftmaster K1D6761-1CC Logic Board Compatible with SL585U, SL585UL, SL595U, SL595UL, SL3000U, & SL3000ULLFM-k1d6761-1cc K1D6761-1CCMC• Logic Board, ACSee More Details
• 1-3 Week Lead Time$475.50
31==== -
Liftmaster K1D8247 Hall Effect Sensor BoardLFM-k1d8247 K1D8247• Hall Effect Sensor BoardSee More Details
• CSW200U
• 1-3 Week Lead Time
• Circuit Boards are Non Returnable$85.50
31==== -
Liftmaster K1D8402-1CC Control BoardLFM-k1d8402-1cc K1D8402-1CC• Motor Drive Board, 1PHSee More Details
• CSW200U, SL3000U
• 1-3 Week Lead Time
• Circuit Boards are Non Returnable$332.50
31==== -
LiftMaster Elite K20-1050B-1RL Motor - 1/2 HPLFM-k20-1050b-1rl K20-1050B-1RL• Motor, 1/2HPSee More Details
• CSW200UL8, SL3000UL, SL3000ULE
• 1-3 Week Lead Time$415.75
31==== -
Liftmaster K20-1050B-1RSX Motor - 1/2 HPLFM-k20-1050b-1rsx K20-1050B-1RSX• Motor, 1/2HP, ACSee More Details
• CSW200U, SL3000U
• 1-3 Week Lead Time$415.75
31==== -
LiftMaster K23-50099 Limit SwitchLFM-K23-50099 K23-50099• Limit SwitchSee More Details
• 1-3 Week Lead Time$18.25
31==== -
Liftmaster K32-37433-1 Gear Reducer - 40-30:1LFM-k32-37433-1 K32-37433-1• Gear Reducer, 40-30:1See More Details
• 1-3 Week Lead Time$308.50
31==== -
LiftMaster K40-3505 Warning SignLFM-k40-3505 K40-3505• Warning Sign, Plastic, "Moving Gates"See More Details
• 1-3 Week Lead Time$15.75
31==== -
Liftmaster K73-37195 ChassisLFM-k73-37195 K73-37195• ChassisSee More Details
• CSW200
• 1-3 Week Lead Time$414.00
31==== -
LiftMaster K75-36260 Lock & KeysLFM-k75-36260 K75-36260• Lock and KeysSee More Details
• 1-3 Week Lead Time$37.75
31==== -
Liftmaster K75-37300-2 E-BoxLFM-k75-37300-2 K75-37300-2• E-BoxSee More Details
• CSW
• 1-3 Week Lead Time$278.25
31==== -
LiftMaster Elite K75-50120 Arm Release KitLFM-k75-50120 K75-50120• Release Arm KitSee More Details
• CSW200, CSW24V, CSW24VH, CSW24VDC, ROBOSWING
• 1-3 Week Lead Time$32.25
31==== -
LiftMaster Elite K75-50189 Limit Switch KitLFM-k75-50189 K75-50189• Limit Switch KitSee More Details
• 1-3 Week Lead Time$105.00
31==== -
LiftMaster Elite K75-50222 Clutch SetLFM-k75-50222 K75-50222• Clutch SetSee More Details
• CSW200 (Post 10/95)
• 1-3 Week Lead Time$62.75
31==== -
LiftMaster Elite K75-50339 Switch - Gate AdjustmentLFM-k75-50339 K75-50339• Gate Adjustment SwitchSee More Details
• CSW200, CSW200U, CSW200UL, ROBOSWING
• 1-3 Week Lead Time$14.00
31==== -
Liftmaster K76-37325 Limit Rack KitLFM-k76-37325 K76-37325• Limit Rack KitSee More Details
• CSW200U
• 1-3 Week Lead Time$133.50
31==== -
Liftmaster K77-37635 Sprocket & Chain KitLFM-k77-37635 K77-37635• Sprocket and Chain KitSee More Details
• CSW200U
• 1-3 Week Lead Time$84.25
31==== -
Liftmaster K77-37638 Antenna w/ Coax CableLFM-k77-37638 K77-37638• Antenna and Coax CableSee More Details
• CSW200U, SL3000U
• 1-3 Week Lead Time$38.00
31==== -
Liftmaster K77-37683 Main Board Standoffs - 10 PackLFM-k77-37683 K77-37683• Main Board Standoffs, Qty 10See More Details
• 1-3 Week Lead Time
• Circuit Boards are Non Returnable$21.75
31==== -
Liftmaster K77-37693 Harness - Wire / ACLFM-k77-37693 K77-37693• Wire Harness, ACSee More Details
• CSW200, SL3000
• 1-3 Week Lead Time$40.25
31==== -
Liftmaster K77-39434 CoverLFM-k77-39434 K77-39434• CoverSee More Details
• CSW200UL
• 1-3 Week Lead Time$850.00
31==== -
LiftMaster K94-34778 Harness - Board to BoardLFM-k94-34778 K94-34778• Board to Board Wire Harness, 24VSee More Details
• 1-3 Week Lead Time$20.50
31==== -
Liftmaster K94-37461 Alarm w/ HarnessLFM-k94-37461 K94-37461• Alarm and HarnessSee More Details
• 1-3 Week Lead Time$56.25
31==== -
LiftMaster Elite K94-50281 Harness Kit - Motor / 1 HPLFM-k94-50281 K94-50281• Wire Harness Kit, 1HP MotorSee More Details
• CSW200, SL3000UL
• 1-3 Week Lead Time$35.00
