Nice HySecurity SLIDESMART-HD Slide Gate Operator
Choose AC or Solar
• HD25 50' x 2,500 Lbs / HD30 50' x 3,000 Lbs
• 115/208/230VAC Power Source or 24VDC Solar
• 24VDC Operational Voltage
• Opens 3/4', 1' or 1-1/4' per Second
• Continuous Duty
• 24VDC Battery Backup System w/ Two 8Ah Batteries
• Up To 4,000' of gate travel on Battery Backup Operation
• Includes EMX IRB-MON Photo Eye, 5' ASO Edge Sensor/Hy2NC Adapter
• 5-Year Limited Manufacturer Warranty
• 3-4 Week Lead Time
• MADE IN USA
• No Additional Tariff Fees
From $3,365.00
To $7,494.70
SKU
HYS-slidesmart-hd-bundle
Product Details
- Duty Cycle: Continuous
- Drive: Electromechanical
- Rate of Travel: 0.75, 1 or 1.25 ft/s (23, 30 or 38 cm/s) Open/Close speed set independently
- Gate Length Maximum: 50 ft (15 m)
- Gate Weight Maximum: HD25 - 2,500 lb (1,134 kg) / HD30 - 3,000 lb (1,361 kg)
- Pull Force: HD25 - 450 lb / HD30 - 500 lb
- UPS Battery Backup Cycles: Field confi gurable to fail open or secure when batteries deplete. Standard battery backup gate travel: Two 8Ah batteries. Up to 4,000 ft (1,219 m) after AC power loss. Extended battery backup gate travel: Two 50Ah batteries. Up to 25,000 ft (7,620 m) after AC power loss.
- Temperature Rating: -13° to 158° F (-25° to 70° C) No heater necessary
- Operating Voltage: 24VDC
- Input Voltage: 115V or 208-230V 60/50Hz
- Accessory Power: 12VDC and 24VDC 1A each
- Included Accessories: 30 ft (9 m) of #40 corrosion resistant roller chain, two steel gate mounting brackets, one premium EMX IRB-MON photo eye, one 5-foot premium ASO edge sensor and a pre-wired Hy2NC adapter
- Communication: USB, RS-232, RS-485
- User Controls: Smart DC Controller with 70+ confi gurable settings. 32 character LCD display and 5 tact buttons or a PC using S.T.A.R.T. software.
- Relays: Two configurable user relays: 30VDC, 3A solid state and 250VAC, 10A electromechanical; Optional Hy8Relay™ for 8 additional relay outputs
- Finish: Zinc rich primer and black powder coated steel cover/chassis
- ETL Listed (UL 325): Usage Class I, II, III, IV
- Cycle Tested: 500,000 cycles
- Warranty: 5 year (7 year single-family residential) w/product registration
| Brand | Nice HySecurity |
|---|
Showcased Accessories
- Gate Locks
- Gate Operator Accessories
- Stand-Alone Access Control
- Multiple Unit / Access Point Control Systems
- Emergency Access
- Loop Detectors
- Loops
- Power Supplies
- All Products
- Google Feed
Product Manuals
Product Brochures
Additional Resources
-
34====
-
Nice HySecurity MX000296 T-Lock w/ KeysHYS-mx000296 MX000296• T-lock and keysSee More Details
• For StrongArm, SlideDriver, SlideSmart HD covers and WedgeSmart DC access doors
• Note: 2 lock units per WedgeSmart DC
• 3-4 Week Lead Time
• No Additional Tariff Fees$76.50
34==== -
Nice HySecurity MX000346 Lithium Battery - 3VHYS-mx000346 MX000346• Controller Battery, 3 Volt, LithiumSee More Details
• For Smart Touch Controller / Smart Touch DC Controller
• For StrongArm | SlideDriver | SwingRiser
• 3-4 Week Lead Time
• No Additional Tariff Fees$8.50
34==== -
Nice HySecurity MX001036 Piezo BuzzerHYS-mx001036 MX001036• Alarm, Piezo Buzzer, "warn before operate"See More Details
• 3-4 Week Lead Time
• No Additional Tariff Fees$66.00
34==== -
Nice HySecurity MX001120 KeyHYS-mx001120 MX001120• Key for #4260-6T LockSee More Details
• StrongArm | SlideDriver II | SlideDriver
• 3-4 Week Lead Time
• No Additional Tariff Fees$32.50
34==== -
Nice HySecurity MX001179 Antenna and Coax CableHYS-mx001179 MX001179• Radio Antenna and Coax CableSee More Details
• For single and dual channel receivers
• 3-4 Week Lead Time
• No Additional Tariff Fees$61.25
34==== -
Nice HySecurity MX001403 Pulley - Drive Belt / 24THYS-mx001403 MX001403• 24T Drive Belt Pulley Mounts to Motor Input ShaftSee More Details
• 9mm wide
• Includes Set Screws
• 3-4 Week Lead Time
• No Additional Tariff Fees$76.50
34==== -
Nice HySecurity MX001404 Pulley - Drive Belt / 36THYS-mx001404 MX001404• 36T Drive Belt Pulley Mounts to Gearbox Input ShaftSee More Details
• Includes Set Screws
• For SlideSmart DC 10F, SwingSmart DC, StrongArmPark DC and WedgeSmart DC models
• 3-4 Week Lead Time
• No Additional Tariff Fees$104.50
34==== -
Nice HySecurity MX001760 Circuit Breaker - 15 AmpHYS-mx001760 MX001760• 15 Amp Circuit Breaker for Solar Powered OperatorSee More Details
• 3-4 Week Lead Time
• No Additional Tariff Fees$17.50
34==== -
Nice HySecurity MX001761 Switch - On/OffHYS-mx001761 MX001761• On/Off SwitchSee More Details
• Double Pole, Single Throw
• 3-4 Week Lead Time
• No Additional Tariff Fees$17.50
34==== -
Nice HySecurity MX001766 Switchable Power Supply Board - 115/230VACHYS-mx001766 MX001766• 115/230 VAC Switchable Power Supply BoardSee More Details
• Toggle Switch to Choose Voltage
• 3-4 Week Lead Time
• No Additional Tariff Fees
• Circuit Boards are Non Returnable$92.75
34==== -
Nice HySecurity MX001920 Brush KitHYS-mx001920 MX001920• 24VDC Motor Brush KitSee More Details
• Replacement Brush Kit for 24 VDC Motor
• Includes 4 Brushes
• 3-4 Week Lead Time
• No Additional Tariff Fees$75.75
34==== -
Nice HySecurity MX001995 MotorHYS-mx001995 MX001995• 24VDC electric motor with encoder for SlideSmart DC onlySee More Details
• 3-4 Week Lead Time
• No Additional Tariff Fees$487.25
34==== -
Nice HySecurity MX002008 Battery Kit - 8AhHYS-mx002008 MX002008• Two 12V, 8Ah batteriesSee More Details
• 3-4 Week Lead Time
• No Additional Tariff Fees$125.75
34==== -
Nice HySecurity MX002013 Battery Kit - 50AhHYS-mx002013 MX002013• Two 12-V, 50Ah batteries for optional extended battery backup kitSee More Details
• 3-4 Week Lead Time
• No Additional Tariff Fees$554.00
34==== -
Nice HySecurity MX002076 Pulley - GearboxHYS-mx002076 MX002076• SlideSmart 60T Gearbox PulleySee More Details
• 60T Drive Belt Pulley Mounts to Gearbox Input Shaft
• Includes Set Screws for SlideSmart DC15 (1FPS)
• 3-4 Week Lead Time
• No Additional Tariff Fees$126.00
34==== -
Nice HySecurity MX002085 Sensor - Switch TargetHYS-mx002085 MX002085• SlideSmart Sensor Switch TargetSee More Details
• Target Proximity Sensor
• Mounts on Operator
• 3-4 Week Lead Time
• No Additional Tariff Fees$43.00
34==== -
Nice HySecurity MX002106 BeltHYS-mx002106 MX002106• Gearbox to motor drive beltSee More Details
• SlideSmart DC 15 (1FPS), and HD25, HD30 models, 100T
• 3-4 Week Lead Time
• No Additional Tariff Fees$42.00
34==== -
Nice HySecurity MX002115 CoverHYS-mx002115 MX002115• SlideSmart 2-Piece CoverSee More Details
• Includes Cover, Base, Lock, Labels, & Fasteners
• 3-4 Week Lead Time
• No Additional Tariff Fees$543.00
34==== -
Nice HySecurity MX002124 Switch - Internal ResetHYS-mx002124 MX002124• Red Internal Reset SwitchSee More Details
• Mounts to Electrical Enclosure
• Includes two Washers
• 3-4 Week Lead Time
• No Additional Tariff Fees$38.75
34==== -
Nice HySecurity MX002136 KeysHYS-mx002136 MX002136• SlideSmart Spare KeysSee More Details
• Spare set of 2 keys for SlideSmart or StrongArmPark Dc Cover Locks
• 3-4 Week Lead Time
• No Additional Tariff Fees$13.00
34==== -
Nice HySecurity MX002181 Pulley - Idler WheelHYS-mx002181 MX002181• Idler wheel pulley for #40 Roller ChainSee More Details
• Includes bolt & bushing
• May also be used for rear mounted installation
• 3-4 Week Lead Time
• No Additional Tariff Fees$33.00
34==== -
Nice HySecurity MX002210 GearboxHYS-mx002210 MX002210• Gearbox with hydraulic fluid for SlideSmart DCSee More Details
• 3-4 Week Lead Time
• No Additional Tariff Fees$472.00
34==== -
Nice HySecurity MX002211 Sprocket - Roller Chain / 30T #40HYS-mx002211 MX002211• 30T #40 Roller Chain SprocketSee More Details
• Including Set Screws
• 3-4 Week Lead Time
• No Additional Tariff Fees$66.00
34==== -
Nice HySecurity MX002573 MotorHYS-mx002573 MX002573• 24VDC, 750W motor with rpm sensorSee More Details
• Used to lift wedge plate
• WedgeSmart DC, SlideSmart DC HD30
• 3-4 Week Lead Time
• No Additional Tariff Fees$523.00
34==== -
Nice HySecurity MX002798 TransformerHYS-mx002798 MX002798• TransformerSee More Details
• 115/208/230VAC input
• 31VAC output or 24VAC nominal output
• 3-4 Week Lead Time
• No Additional Tariff Fees$366.25
34==== -
Nice HySecurity MX3037-0 Control BoardHYS-mx3037-0 MX3037-0• Smart DC Controller Board, universal programmingSee More Details
• Note: Must program operator type when installing in operator
• 3-4 Week Lead Time
• No Additional Tariff Fees
• Circuit Boards are Non Returnable$485.00
34==== -
Nice HySecurity MX4018 Edge Sensor Module - N/C AdapterHYS-mx4018 MX4018• Wired Edge Sensor N/C adapter (Hy2NC™), 2 channelSee More Details
• Note: Each channel will allow N/C monitoring of one wired Edge Sensor with an 8.2k or 10k resistor
• 3-4 Week Lead Time
• No Additional Tariff Fees$96.25
34==== -
Nice HySecurity MX3037R-0 Control Board - ReconditionedHYS-mx3037r-0 MX3037R-0• Reconditioned Smart DC Controller Board, universal programmingSee More Details
• Note: Must program operator type and input power type when installing in operator
• Reconditioned parts carry the same Manufacturer Warranty as new replacement parts
• Call for availability
• 3-4 Week Lead Time
• No Additional Tariff Fees
• Circuit Boards are Non Returnable$403.25
34==== -
Nice HySecurity MX3796 Circuit Breaker - 5AHYS-mx3796 MX3796• Circuit Breaker, 5ASee More Details
• 3-4 Week Lead Time
• No Additional Tariff Fees$18.50
34==== -
Nice HySecurity MX4306 Cover KitHYS-mx4306 MX4306• SlideSmart HD cover kitSee More Details
• Includes cover, lock, and labels
• 3-4 Week Lead Time
• No Additional Tariff Fees$484.00
34==== -
Nice HySecurity MX4308 Motor Plate AssemblyHYS-mx4308 MX4308• PEM motor plate assembly for SlideSmart DC HDSee More Details
• 3-4 Week Lead Time
• No Additional Tariff Fees$47.00
34==== -
Nice HySecurity MX4312 U-Bolt Spacer PlateHYS-mx4312 MX4312• The U-bolt spacer plate provides necessary reinforcement for post mounting u-boltsSee More Details
• Also necessary for water resistance
• 3-4 Week Lead Time
• No Additional Tariff Fees$18.50
34==== -
Nice HySecurity MX4369 Sprocket - Gearbox Output ShaftHYS-mx4369 MX4369• Gearbox output shaft sprocketSee More Details
• #40 roller chain, 24T
• Includes set screws
• 3-4 Week Lead Time
• No Additional Tariff Fees$104.50
34==== -
Nice HySecurity MX4621 Hy5B™ 2.0 Loop DetectorHYS-mx4621 MX4621• Improved loop detector module with digital interface to SmartCNX and all other HySecurity controllersSee More Details
• Automatically sets sensitivity
• Automatically compensates for gate movement
• Advanced loop diagnostics
• Note: CNX operators not compatible with MX4125 vehicle detector
• 3-4 Week Lead Time
• No Additional Tariff Fees$232.00
