FAAC 390 Electromechanical Column Mount Swing Gate Operator
• 14' x 600 Lbs
• 115VAC Power Source / 24VDC Operating Voltage
• Opens 90° in ~ 12" per Second
• Continuous Duty Cycle
• 24VDC Battery Backup System w/ Batteries
• Includes Receiver, 2 Transmitters & Photo Eye
• 3-Year Limited Manufacturer Warranty
• 3-5 Day Lead Time
From $1,815.00
To $3,322.00
SKU
FAC-390-bundle
Product Details
Single Kit Includes:
- 1 Operator 390 - 104579- 2 Limit Switch - 390682
- 1 E024U Enclosure Kit - 3350.1
- 2 Batteries 12V 8 Ah - 3540
- 1 Receiver 433 RC Plug In - 787856
- 2 4-channel transmitter XT4 433 RC - 787453
- 1 Pair of XP 30 photobeam photocells - 785105
- 2 XP 30 adapters for conduit connection - 401064
Secondary Kit Includes:
- 1 Operator 390 with limit switches - 104579.5- 1 Junction Box for electrical connections - 3365.1
40* Cable AWG 12 - 2 conductors cable (operator) - 1 Ft. - 2197
40 Cable AWG 18 - 3 conductors cable (limit switches) - 1 Ft. - 2192
* The AWG 12 cables can be used for connections of up to 50' of length between the operator and the control board.
- Non reversing operator, does not require external locks
- Easy to install, no modifications to the gates are necessary
- Ideal for gates mounted on large columns
- Adjustable limit switches (optional)
- Maximum safety thanks to the E024U control board reverse on contact feature
- Built in battery backup to ensure operation in case of power outage
- Compliant with UL325 for Class I,II,III and IV applications
Note:
• Mounting dimensions, wind factor and gate design will affect performance specification• Use frequency is measured at an ambient temperature of 72°F (20°C) . Temperature variation will affect it.
• An electric or magnetic lock is recommended for any gate longer than 12 ft (3.6 m).
| Brand | FAAC |
|---|
