Trine EN400-32D Electric Strike

Be the first to review this product

Choose Voltage & Handing • Heavy duty 2,000+ lbs UL® tested • Durability of 1,000,000+ life cycles • Outdoor UL® rating allows the strike to be used anywhere - especially good for gates • Fail secure/Fail safe field reversible on DC units • Contains a one piece locking mechanism with one Solenoid • Left and Right handing is field reversible • Great for all high humidity environments like at marinas and pools

MPN: EN400-32D

$346.00

SKU

TRN-en400-32d

Voltage

12VDC

24VDC

Handing

Left

Right

Qty

Skip to the end of the images gallery

VIEW MANUALS, BROCHURES & VIDEOS

Skip to the beginning of the images gallery

Overview

Product Details

For new or replacement installations in wood or metal jambs. Use with cylindrical locksets, mortise locks without dead bolts, and mortise exit devices with up to 7/8" throw.

UL® Listed 10C - Fire-rated - Class A, 3-hour, single swing door
UL® Listed 1034 - Indoor/Outdoor Burglary Resistant
UL294 (6th Edition) listed
NYC MEA 79-01-E

Volts	Current	Ohms (Ω)	Duty	Sound	Wire

12AC	0.7	4.5	Intm.	Buzz	1-Blue,
12AC	0.7	4.5	Intm.	Buzz	1-Orange/White
24AC	0.37	18	Intm.	Buzz	1-Blue,
24AC	0.37	18	Intm.	Buzz	1-Black/White
12DC	0.28	43	Intm./Cont.	Silent	2-Orange/White
24DC	0.15	164	Intm./Cont.	Silent	2-Black/White
